Tanker Monitoring Smart Bluetooth Padlock PA66 With Tracking Software

Minimum Order Quantity : 1 Price : USD488-448/pcs
Packaging Details : carton box Delivery Time : one week
Payment Terms : L/C, T/T Supply Ability : 10000pcs
Place of Origin: China Brand Name: Jointech
Certification: ATEx. IECEx Model Number: JT802

Detail Information

Smart Bluetooth Padlock: Tanker Monitoring Weight: 2.4kg
Application: Oil Tanker Transportation Network: 2G,4G
Protection Grade: Ip67waterproof Connection: Bluetooth, 3G/4G Sim Card, 2G Sim Card
Unlock: Bluetooth,APP
High Light:

Tanker Monitoring Smart Bluetooth Padlock

,

Tracking Software Smart Bluetooth Padlock

,

PA66 GPS Tracking Lock

Product Description

Smart Bluetooth Padlock Tanker Monitoring GPS tracking lock with tracking software



Tank truck intelligent valve lock JT802 is a slave lock product developed on the basis of the existing product functions of JT701D/JT701L intelligent electronic locks. JT701D is the master lock, and JT802 is the slave lock, which can be applied to the application scenario of the tank truck customer with one master and multiple slaves (multi-valve) .



Tanker Monitoring Smart Bluetooth Padlock PA66 With Tracking Software 0



Features
1. Lora and Bluetooth wireless communication

2. Anti-explosion certification(TUV)

3. Low power consumption, 2 years working life

4. Smart unlock + manual unlock





Items Description
Shell material Aluminum alloy, PA66+ glass brazing, oil-proof material
Battery Built-in disposable lithium manganese battery, CP705050 (4000mAh)
Support Bluetooth Support Bluetooth and mobile phone APP communication, realize related functions, antenna onboard, size 10*15 or more
Support LORA Lora communicates with the cockpit host, the antenna size is more than 15*50, and the distance from the PCB is more than 8mm
Indicator light Working status indicator: red
Lock working mode

1. Bluetooth lock mode: only use Bluetooth to unlock, do not use Lora to unlock;

2. Double lock mode: use LORA unlock + Bluetooth unlock together.

Power consumption and battery life

The working current of the motor is 100mA, and it takes about 2s to open and close the lock.

Lora is usually closed, and an event generates a wake-up and sends it to the host. When the host with an unlock command, press the key to wake up and connect to the host to obtain the unlock command to unlock, the average working current is 16mA during work, and each work is estimated to be 60 seconds.

Standby power consumption is about 50uA.

Turn the lock on and off 10 times a day, unlock and lock once. Power consumption: 0.155mAh.

Life time: 2 years.

Explosion-proof certification

The valve lock conforms to intrinsically safe explosion-proof;

The handheld terminal complies with intrinsically safe explosion-proof.


Tanker Monitoring Smart Bluetooth Padlock PA66 With Tracking Software 1
HIGHLIGHT: Unlock by Blutooth-nearby/Lora command-remote/manual Application: Fuel Transportation security usually used on fuel tanker valves.
Tanker Monitoring Smart Bluetooth Padlock PA66 With Tracking Software 2
