Oil Tank Truck Bottom Outlet Valve Lock Smart Unlock with IEC ex certification

Product Details:
Place of Origin: Guandong,China
Brand Name: White Brand or customize
Certification: CE,ISO9001:2015, TUV
Model Number: JT802
Payment & Shipping Terms:
Minimum Order Quantity: 2 unit
Price: negotiate
Packaging Details: Carton/wooden box/ customized
Delivery Time: 2-7 days
Payment Terms: T/T
Supply Ability: 10000 units per month

Detail Information

Product Name: Oil Tank Truck Smart Lock Weight: 2.4kg
Waterproof: IP67 Grade Unlocking: Remote Unlock, Bluetooth, Physical Key
Function: Tanker Valve Bluetooth Smart Lock Application: Oil Tank Truck
Standard Battery: 4000mAh Brand: OEM Brand
Warranty: 1 Year Dimension: 248.5*190.1*165mm
High Light:

Anti Explosion Smart Bluetooth Padlock


Tanker Valve Smart Bluetooth Padlock


Anti Fuel Theft Bluetooth Smart Lock

Product Description

Oil Tank Truck Bottom Outlet Valve Lock Smart Unlock with IEC ex certification 0

Oil Tank Truck Bottom Outlet Valve Lock Smart Unlock with IEC ex certification


Once upon a time, many clients ask us whether there's a ATEX certification for GPS lock, because they need to monitor fuel tanker.  However, there's no such a GPS smart lock can do, until Jointech developed it in 2020.


This development take 2 years along with various change and modification to meet the IEC EX certification request. And finally JT802 valve lock launched.


Smart Bluetooth padlock JT802 is target to built-in the oil tanker valve, to intelligently control the outlet valve lock open and close. The unlock method can be Bluetooth nearby, can be remotely via Lora master, can be unique physical key.


It can work alone itself, with 2 years battery life. It can also work together with master lock for multi-valves controlling together.

Catch me to get some specific case study!


  • Remote and Bluetooth wireless communication

  • Anti-explosion certification(ATEX+IEC EX)

  • Low power consumption, 2 years working life

  • Smart unlock + manual unlock



Basic Function

Transmission mode


Lock status detecting

Real time

Unlock option


Data info

Lock status; unlock detecting; left battery; real time location.

Data storage

1000 pcs


Low power

Valve remove

Top Cover open

Manual lock cover open

Offline alarm (valid with JT701D master)

Battery management

Low power working mode

Sleep mode

Low power deep sleep mode

Battery life

2 years

[suppose 10 unlock per day]

Basic Function

Wake-up resource

Bluetooth connection

Manual lock cover open


Valve remove

Manual wake-up






Working and storage temp


Relatively humidity



4000mAh, disposable Lithium manganese battery



Average working current


Standby working current



IECEx: Ex ib IIB T4 Gb

ATEx: II 2 G Ex ib IIB T4 Gb


Unique for Oil tank truck Customized Service:

  • Integrated Door Magnetic induction, easy installation

  • Bluetooth/Remote authorization control

  • Alarm when open the door illegally

  • Unique label customization with your brand

Joint Cloud tracking platform for remote control

  • Real-time tracking GPS container lock

  • Track trace reply

  • Reports of tracking detail, alarms, driving behavior...

  • Unlock and unlock case recording

  • Remote control

  • Unlock in certain Area only

Smart Bluetooth Padlock FAQ:

1) Do you have your own factory?
A: Yes, our factory and working building locating in Guangdong, China with 15 history.
2) Why choose us?
A: We have worked with 50 customers from Fortune 500, which include Huawei, Carefour, Dia, DHL,SGS......etc,
in cooperating with those internataional enterprises and orgnizations, we can fully satisfy your needs in mobile
assets monitoring field.
3) Do you provide customized hardware and software?
A: Yes, we can provide not just customized hardware, but also software funcationalities.
